TS-VRIN12M-64CIVR8SM381
Core Guard 64CH AI NVR
- Full real-time 4K network access, H265+, H256, H264 three-stream decoding.
- Maximum support for simultaneous comparison of 16 faces and 5000 face libraries.
- Black and white list classification, support the linkage alarm of face black and white list classification.
- Support IPC centralized management, including IPC parameter configuration, information import and export, real-time information acquisition and other functions.
- Brand new UI operation interface, support one key to turn on the recording function.
- Support instant playback function, dual password authentication, zero channel setting.
- Support network detection (network traffic monitoring, network packet capture, network smoothness) function.
- Support network disk function (IPSAN, NAS).
- Support face recognition linkage front-end camera, equipment local alarm output function.
| XVR Parameter | |
| Model NO | TS-VRIN12M-64CIVR8SM381 |
| Operating system | Embedded Linux |
| bandwidth | 512M |
| Video format | H.265+/H.265 /H.264 |
| Clarity | 4K / 5MP / 3MP / 1080P / 720P / D1 |
| Smart function | Human form detection, target counting, electronic fence, retrograde detection, off-post detection, face detection (requires front-end camera support) |
| Video mode | Timing recording and alarm recording, timing recording, alarm recording, stop recording, motion detection recording , network disconnection supplement recording (requires front-end support) |
| Replay ability | Support 1*4K/ 4*4K/9*3MP/16*1080P video synchronization playback |
| Playback mode | Regular playback, instant playback, event playback, external file playback |
| Backup mode | U disk, network backup |
| Face recognition | 16- way front-end comparison |
| Video | |
 | |
| Video, audio, alarm | |
| Video input | 64CH digital (4000X3000) + 64CH preview + 16CH playback + 16-channel front-end face matching machine 36CH digital (4000X3000) + 36CH preview + 16CH playback 64CH digital (4000X3000) + 64CH preview + 16CH playback Support importing 5000 face libraries |
| Video output | 1 HDMI, 1 VGA |
| Audio input and output | 1 channel RCA audio input, 1 channel RCA audio output, HDMI audio |
| Alarm input and output | 4 channels alarm input 4 channels alarm output |
| Storage | |
| hard disk | 9 SATA, maximum support 8TB |
| E-Sata | 1 |
| The internet | |
| network port | 2*RJ45 10M/100M/1000M adaptive |
| Internet function | DDNS,EMAIL,UPNP,NTP,DHCP,IP Filter,PPPoE,P2P |
| Phone monitoring | iPhone, Android |
| Peripheral port | |
| USB | 3 USB (2 USB2.0, 1 USB3.0) |
| RS232 | N/A |
| RS485 | 1 |
| Other | |
| Certification | UL;FCC;CE;ROHS |
| Housing | METAL |
| power supply | AC100-240V 200W |
| power | ≤50W(without HDD ) |
| size | Equipment: 440mm×430mm×90mm, Packing: 539mmX530mmX225mm |
| weight | Net weight.: 7.4Kg; Gross weight: 9.8Kg |
